GSE Weight Indicators

GSE 350 Weight Indicators
A sophisticated indicator at an affordable price.  20-bit A/D converter, parts counting.  Six selectable fixed-format and one custom format data output string.  Front panel keys are ZERO/CLR, PRINT, UNITS, TARE, SELECT/ON.  Indicator lights for lb, kg, Neg, Mot, Zero, Gross, Net, Quantity, Setpoint 1,2,3.  Zinc die cast or Nema 4X stainless steel enclosure. NTEP 98-092 III/IIIL 10,000 divisions.

GSE-350
stainless steel

Zinc die cast

Stainless

GSE 450/455/550 Weight Indicators
The 450/550 series is designed to accomodate a variety of weighing & force measurement applications.  Parts counting, accumulation.  Custom data string permits the RS232 output to transmit control codes, headers, and custom labels.  Twpo flexible setpoints offer 6 modes of operation.  Filling, emptying, checkweighing & batching routines offer 3 variations of status indication and a learn mode to auto/manual preact.  Front panel keys for 450 are ZERO/CLR, PRINT, UNITS, TARE, SELECT.  GSE455 also has ID, Target, 0 thru 9.  Units are lb, kg, g, lb-0z and 1 custom unit.  Optional time & date.  Nema 4X stainless steel enclosure.

GSE-450

GSE-455

GSE-455

GSE-550
